40KN Safety Hydraulic Puller Tensioner Machine For Overhead Line Tranmission

Name: 40KN Safety Hydraulic Puller Tensioner Machine For Overhead Line Tranmission
Brand: Shenhong
Price: 1 USD

Buy cheap 40KN Safety Hydraulic Puller Tensioner Machine For Overhead Line Tranmission product

Brand Name : Shenhong

Model Number : SA-YQ40

Certification : ISO

Place of Origin : Jiangsu,China

MOQ : 1 set

Price : US $35000~60000

Supply Ability : 5 Set/Sets per Month

Delivery Time : 20 work days after deposit

Packaging Details : Export case

Max linepull : 40KN

Continous line : 35KN

Maximum Pulling Speed (km/h) : 5

Bullwheel Bottom of Groove Diameter (mm) : 400

Number of Bullwheel Grooves : 7

Maximum Through Connector Diameter (mm) : 50

Engine Power / Speed (kW/rpm) : 60/2000

Contact Now

40KN Safety Hydraulic Puller Tensioner Machine For Overhead Line Tranmission

Our SA-YQ40 Hydraulic Puller has an overload automatic protection function. The maximum traction force for conductor stringing operation is able to be preset. Another function is the automatic action of spring applied hydraulically released brake. Owing to it, our product is safe to be operated, in case that the motor suddenly turns off, or other reasons cause the hydraulic failure.

In use of this SA-YQ40 Hydraulic Puller, both pulling speed and traction force are steplessly adjustable. The pull in the rope can be clearly displayed on the line pull gauge. Moreover, our product employs the steel wire rope automatically winding device, for automatic rope arrangement as well as easy loading and unloading.

Main Specifications

Model	SA-YQ40 Hydraulic Puller
Maximum Traction Force (kN)	40
Continuous Tractive Effort (kN)	35
Maximum Pulling Speed (km/h)	5
Bullwheel Bottom of Groove Diameter (mm)	Φ400
Number of Bullwheel Grooves	7
Maximum Diameter of Suitable Steel Rope (mm)	Φ16
Maximum Through Connector Diameter (mm)	Φ50
Engine Power / Speed (kW/rpm)	60/2000
Dimensions (mm)	3500× 2000× 2300
Weight (kg)	2500

Main Components

Engine	Cummins (DONGFENG ) water cooled engine
Main Variable Pump and Main Motor	Rexroth (BOSCH)
Reducer	RR (Italian)
Main Hydraulic Valve	Rexroth (BOSCH)
Radiator	AKG
Hydraulic Instrument
Suitable Drum	Model GSP1400 (Item number: 07125C)
