Multifunction Cable Drum Trailer Cable Reel Carrier For Hauling And Lifting

Brand Name : shenhong

Model Number : LZ

Certification : BV,CE,ISO

Place of Origin : Jiangsu,China

MOQ : 1 set

Price : negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10 Set/Sets per Month

Delivery Time : ten days after the deposit

Packaging Details : PVC plastic

Power source : hand

Capacity : 3-10Ton

Brake : Automatic Hydraulic Brake

Diameter : 800-1200(Customized)

Color : red, yellow,green,ect.

Max coil diameter : 2300, 2800, 3300, 3500mm

Max coil width : 1250,1450,1750,1850mm

Weight : 900,1500, 2300,2800kg

Contact Now

Multifunction Cable Drum Trailer Cable Reel Carrier For Hauling And Lifting



Application

It is used for cable drum hauling and cable pulling-pushing.The machine is equipped with automatic braking device, so it can brake effectiveiy by moving clutch.It is flexible steering,and can change angle at random. It is a necessary tool for electric construction because of its simple operation and easy maintenance.



Note

We can make products with special specification as your requirements.



Technical data of Multifunction cable drum trailer, cable reel carrier for hauling and lifting

Model Rated Load Weight(kg) Applicable coil diameter(mm) Applicable coil width(mm) Overall dimensions(mm)
LZ-3T 3T 900 ≤2300 ≤1250 3800×2300×2200
LZ-5T 5T 1500 ≤2800 ≤1450 4000×2600×2500
LZ-8T 8T 2300 ≤3300 ≤1750 4300×3200×2700
LZ-10T 10T 2800 ≤3500 ≤1850 4300×3400×2800



Multifunction Cable Drum Trailer Cable Reel Carrier For Hauling And Lifting



Shipment

1. The machine will be shipped in container

2. We will ship the products within one month normally after receiving the payment.

3. Stock is available for standard product.



Payment

1. We accept T/T and L/C.

2. Please send swift copy of T/T if you arrange payment by T/T

3. Please send us the L/C draft to us before issue L/C.
